Top-mounted freezer cabinet / supermarket freezer top - Liebherr - PIZ 250 (-) - New product

The Liebherr Top-Freezer overhead cabinet with an impressive length of 2500 mm offers an ideal combination of generous storage space, first-class performance and modern design. This freezer overhead cabinet is specially designed to provide an efficient and space-saving freezer solution in professional environments such as restaurants, hotels or commercial kitchens. Thanks to its robust workmanship, well-thought-out interior design and powerful cooling technology, it meets the high demands placed on commercial refrigeration appliances.

Performance and consumption

• Energy efficiency class: C
• Energy consumption per year: 3,097 kWh/a
• Energy consumption in 24 hours: 8.484 kWh / 24h
• Climate class: 3
• Temperature class: L1
• Noise output: 60 dB
• Maximum temperature of the warmest measuring package: -15 °C
• Maximum temperature of all measuring packages: -18 °C
• Voltage: 220-240 V ~
• Frequency: 50-60 Hz
• Connection value: 5.0 A
• Climate class (safety standard): 3
• Ambient temperature: +16°C to 25°C

Control and functions

• Temperature display inside freezer compartment: digital
• Interface: RJ45
• Potential-free contact: ✔
• Warning signal in the event of a fault: optical
• Touch control: electronic

Freezer compartment

• Gross volume of freezer compartment: 1,160 l
• Net capacity for freezing: 689 l
• Cooling system: Dynamic
• Refrigerant: R 290
• Filling quantity of 1st refrigerant: 125 g
• Adjustable temperature range: -19 °C to -21 °C
• Cooling technology: NoFrost
• Defrosting process: automatic
• Number of shelves: 8 (Only one row of wire shelves included)
• Interior lighting: LED lighting

Design and materials

• Case color: Gray
• Side wall material: Steel
• Inner container material: White-coated aluminum
• Door material: Insulated glass door
• Material of adjustable shelves in freezer compartment: Plastic-coated racks
• Handle: Ergonomic bar handle
• Material of adjustable feet: Galvanized steel

Construction and installation

• Connection cable (length): 2,300 mm

Specifications

• Total gross capacity: 1,160 l
• Total net capacity: 689 l
• External dimensions (height / width / depth): 143 / 250 / 76 cm
• Height / width / depth (with packaging): 2,050.0 / 2,650.0 / 810.0 mm
• Internal dimensions (height / width / depth): 80.0 / 238.0 / 40.0 cm
• Product presentation area: 1.54 m²
• Weight (without packaging): 360 kg
• Weight (with packaging): 420 kg

Space miracle with a length of 2500 mm

With a total length of 2500 mm, the Liebherr Top-Freezer offers a particularly large usable capacity, which is ideal for storing large quantities of frozen products. The generous capacities make it the perfect companion in environments where a lot of frozen goods have to be stored and quickly accessed every day. Despite its considerable size, the slim and ergonomic design ensures that the freezer overhead cabinet can be easily integrated into different rooms without taking up too much space.

Efficient room layout and easy organization

The interior of the Liebherr Top-Freezer is optimally designed for efficient food storage. With several stable and removable shelves, the overhead cabinet offers flexibility in organizing the goods. Thanks to the well-thought-out arrangement of the compartments, you can quickly store and find frozen products. The door compartments offer additional storage space for smaller items, while the transparent design of the interior makes it easier to see the entire contents.

Powerful cooling technology for constant temperatures

The Liebherr Top-Freezer is equipped with the latest deep-freezing technology to ensure constant and precise temperature control. The powerful cooling ensures that all food remains evenly and safely frozen, which is particularly crucial in a professional environment. The overhead cabinet works extremely energy efficiently and reliably, so you can rely on consistently high performance. Even at high ambient temperatures, the internal temperature remains stable and protects your valuable frozen supplies from loss of quality.

Energy-saving and environmentally friendly

Despite its size and performance, the Liebherr Top-Freezer is particularly energy efficient and environmentally friendly. Thanks to innovative cooling technologies and excellent insulation, the freezer is one of the most economical devices in its class. This not only helps reduce operating costs, but also protects the environment. The energy efficiency of the device makes it a responsible choice for companies that value sustainable solutions.

Robust construction and high durability

Liebherr has always stood for quality and durability, and this freezer top cabinet is no exception. The top cabinet is made of high-quality, robust materials that make it resistant to the daily challenges of the catering industry and other demanding environments. The solid workmanship and the use of durable components guarantee a long service life and high resilience, even with intensive use.

User-friendliness and comfortable operation

Despite its size, the Liebherr top freezer is easy to use. The ergonomic design of the doors and handles allows for easy opening and closing, while the integrated LED interior lighting ensures excellent visibility of the stored products. The precisely adjustable temperature control allows you to set the optimal conditions for storing your frozen goods.

Note: Despite careful data maintenance, we reserve the right to make technical changes, errors and deviations in the image and text content compared to the original device.
